  • 437-015-008G VDO Cockpit Vision Speedometer 300 Km/h 100mm 12-24V

VDO Cockpit Vision Speedometer 300 Km/h 100mm 12-24V

Part-number:

VDO 437-015-008G

  • Color: Black
  • Panel hole diameter: 100 mm - 4"
  • Measuring range: 0 to 300 Km/h
  • Supply voltage: 12-24 Volts DC
  • Retail packaging 1 Speedometer
Logistical information:
Expired productClick here for detailed information.
  • HS Code: 90292031
  • Ean Code: 4103590200105
  • Weight: 0.64kg
Discontinued article
Replacement article on request

Functional description Cockpit Vision Speedometer:

VDO Cockpit Vision 437 015 008G Specifications:

Dimensions and assembly:

Built-in (Hole) diameter and Outside diameter: 100 mm - 4 Inch and 105 mm - 4 1/8 Inch
Installation depth: 91 mm
Panel thickness with spinlock nut: Optional 0.5mm - 23mm
Panel thickness with bracket mounting: 0.5 mm - 12 mm
Flushmount mounting: None

Functional:

Analog speed measurement range: 0 to 300 Km/h
Display Features:
Odometer
Trip meter
Input signal analog speed meter: RPM Induction Sensor
RPM Hall sensor
RPM Blocking oscillator sensor
Measurement accuracy: No Statement VDO Available
Connection: 8-Pin flat plug connector 6.3 x 0.8mm
Connection scale lighting: Flat plug 6.3 x 0.8mm (4x)

Power supply:

Supply voltage: 11 - 30 Volt DC
Power consumption without shell lighting: < 100 mA
Reverse polarity protection: Yes
Short-circuit resistance: No VDO

Scale & pointer:

Graduation: 320°
Scale color: Black
Scale lighting: Backlight Double 12V - 2 Watt White - Green - Red and 24V - 2 Watt - Optional
Pointer: Red backlight
Alarm indication: None
Programmable: No

Version:

Model: Cockpit Vision
Front glass type: Single - Anti-Glare
Standard front ring: Triangle black (Screw ring)

Degree of protection and certification:

Front protection class: IP64 (DIN 40050) - Ozone resistant - UV resistant
Back protection class IP42 (DIN 40050)
Relative humidity: No statement VDO available
Operating Temperature: -20°C to +70°C
CE Certification: Yes
DNV GL Certification: No Statement VDO Available
Vibration test 8 hours: Max: 1G - 25Hz - 2000Hz
EMC Test: According to EN 13309 and ISO 13677
Nominal position: NL 0 to NL 90 - DIN 16257
Housing: Plastic Fire Retardant

Retail packaging:

  • VDO Cockpit Vision 437 015 008G Speedometer
  • Order connection material separately
  • Chrome-plated mounting bracket
437-015-008G

Data sheet

Speed Measurement Range
0 - 300 Km/h
Warning indication
None
Supply voltage
11 - 30 Volt DC
Packaging
VDO Instrument retail
Application
VDO Navigation
Signal analog
Tacho impulse signal
Series
VDO Cockpit Vision
Lens
Plastic single anti-reflective
Color
Black
IP Class front
IP64 (DIN 40050)
Installation size
100 mm - 4 Inch
Functionality
Speedometers multifunction
Front ring interchangeable
Yes - Special tools required
Front ring model
Black triangle
Communication
Analogue
Category
Speedometers
Article status
Expired product

Specific References

EAN13
4103590200105
MPN
437-015-008G
