VDO OceanLine Tachometer 1,800 RPM Black - Red Pointer - 85mm - 12 Volt
Part-number:
VDO N02-012-302
- Color: Black - Red hand
- Panel hole diameter: 85 mm - 3 3/8"
- Measuring range: 0 to 1,800 RPM
- Front: Double glazing - 12 Volt
- Retail packaging 1 Tachometer
Logistical information:
- Weight: 0.50kg
N02-012-302
Data sheet
- Speed Measuring range
- 0 - 1,800 RPM
- Warning indication
- Red LED Via plus and minus
- Supply voltage
- 8 - 32 Volt DC
- Packaging
- VDO Instrument retail
- Application
- VDO Engine control
- Signal analog
- Tacho impulse signal
- Series
- VDO Marine OceanLine
- Lens
- Plastic double anti-fog
- Color
- Black
- IP Class front
- IP67 (IEC 60529)
- Input
- Analogue
- Installation size
- 85 mm - 3 3/8 Inch
- Functionality
- Tachometers multifunction
- Front ring interchangeable
- Yes - Clip-on
- Front ring model
- Black triangle
- Communication
- Analogue
- Category
- Tachometers
- Article status
- Discontinued product
Specific References
- MPN
- N02-012-302
